Rotator / Carousel Mode

Switch between two Carousel modes

  • Enabling RadRotator's Carousel mode


    Telerik RadRotator supports (starting from Q2 2010) two additional RotatorTypes - Carousel and CarouselButtons. Modes can be set using RotatorType property of the control.

    Important: The Carousel mode of RadRotator works best, in case there is only a single image in every rotator item.

    • Enabling Carousel mode directly on the markup:
      <telerik:RadRotator ID="RadRotator1" runat="server" Width="810px" ItemWidth="300"
          Height="350px" ItemHeight="220" ScrollDuration="500" FrameDuration="2000" EnableRandomOrder="true"
          PauseOnMouseOver="false" Skin="Windows7" RotatorType="Carousel">
      . . . . . . . . . . . . . . . . . . . . . . . .
    • Enabling Carousel mode in codebehind:
      RadRotator1.RotatorType = RotatorType.Carousel;

    If the RotatorType="CarouselButtons" is set, then the items are moved by clicking the RadRotator's default navigation buttons located on the left and right side of the control.

    In this example, RadRotator shows the content of a directory. The images are loaded using the GetFilesInFolder method, shown in the codebehind file.

Source Code

C# VB.NET
Show code in new window Demo isolation steps
  • <%@ Page Language="c#" AutoEventWireup="true" Inherits="Telerik.Web.Examples.Rotator.CarouselMode.DefaultCS"
        CodeFile="DefaultCS.aspx.cs" %>

    <%@ Register TagPrefix="qsf" TagName="Header" Src="~/Common/Header.ascx" %>
    <%@ Register TagPrefix="qsf" TagName="HeadTag" Src="~/Common/HeadTag.ascx" %>
    <%@ Register TagPrefix="qsf" TagName="Footer" Src="~/Common/Footer.ascx" %>
    <%@ Register TagPrefix="telerik" Namespace="Telerik.QuickStart" %>
    <%@ Register TagPrefix="telerik" Namespace="Telerik.Web.UI" Assembly="Telerik.Web.UI" %>
    <!DOCTYPE html PUBLIC "-//W3C//DTD XHTML 1.1//EN" "http://www.w3.org/TR/xhtml11/DTD/xhtml11.dtd">
    <html xmlns="http://www.w3.org/1999/xhtml">
    <head runat="server">
        <qsf:HeadTag ID="Headtag1" runat="server" />
        <style type="text/css">
            .rotNoButtonsBack, .rotWithButtonsBack
            {
                margin-left: auto;
                margin-right: auto;
                height: 350px;
                font-family: Arial;
                padding: 0;
            }
            .rotNoButtonsBack
            {
                width: 810px;
                background: url("back.jpg");
            }
            .rotWithButtonsBack
            {
                width: 831px;
                height: 352px;
                background: url("back.jpg") no-repeat scroll 21px 1px transparent;
            }
            .horizontalRotator
            {
                margin-left: auto;
                margin-right: auto;
            }
        </style>
    </head>
    <body class="BODY">
        <form id="Form1" method="post" runat="server">
        <qsf:Header ID="Header1" runat="server" NavigationLanguage="c#" />
        <telerik:RadScriptManager ID="ScriptManager1" runat="server">
        </telerik:RadScriptManager>
        <telerik:ConfiguratorPanel runat="server" ID="ConfigurationPanel1" Enabled="true"
            Title="Switch between two Carousel modes" Expanded="true" Style="text-align: left;"
            HorizontalAlign="Right">
            <asp:RadioButtonList ID="dblCarouselModes" runat="server" AutoPostBack="true" OnSelectedIndexChanged="dblCarouselModes_SelectedIndexChanged">
                <asp:ListItem Selected="True" Text="Carousel" Value="Carousel"></asp:ListItem>
                <asp:ListItem Selected="False" Text="CarouselButtons" Value="CarouselButtons"></asp:ListItem>
            </asp:RadioButtonList>
        </telerik:ConfiguratorPanel>
        <div class="mainDiv">
            <asp:Panel ID="RotatorWrapper" runat="server" CssClass="rotNoButtonsBack">
                <telerik:RadRotator ID="RadRotator1" runat="server" Width="810px" ItemWidth="300"
                    Height="350px" ItemHeight="220" ScrollDuration="500" FrameDuration="2000"
                    PauseOnMouseOver="false" RotatorType="CarouselButtons" OnClientItemClicked="OnClientItemClicked">
                    <ItemTemplate>
                        <asp:Image ID="Image1" runat="server" ImageUrl='<%# Container.DataItem %>' AlternateText="<%# VirtualPathUtility.GetFileName(Container.DataItem.ToString()) %>" />
                    </ItemTemplate>
                </telerik:RadRotator>
            </asp:Panel>
            <script type="text/javascript">
            function OnClientItemClicked(sender, args)
            {
                sender.set_currentItemIndex(args.get_item().get_index(), true);
            }
            </script>
        </div>
        <qsf:Footer runat="server" ID="Footer1" />
        </form>
    </body>
    </html>
